4A Boost Buck DC-DC adjustable Step Up Converter XL6009 Module

Rated 0 out of 5

In stock

XL6009 DC-DC boost (step-up) converter module with adjustable output voltage and up to 4A current. Ideal for Arduino, battery systems, and power supply applications.

Add to Wishlist

Compare

Description

The XL6009 DC-DC Adjustable Boost Converter Module is a high-efficiency power module designed to step up input voltage to a higher adjustable output voltage. Based on the XL6009 switching regulator, this module delivers stable performance with low ripple and high efficiency.

It supports a wide input voltage range from 3V to 32V and provides an adjustable output voltage up to 35V, making it suitable for a variety of applications including battery-powered devices, LED drivers, and embedded systems.

The onboard multi-turn potentiometer allows precise voltage adjustment, enabling flexible configuration for different projects. Its compact size and high current capability make it a reliable choice for DIY electronics as well as industrial applications.

Additional information

Input Voltage	3V – 32V DC
Output Voltage	5V – 35V DC (adjustable)
Output Current	Up to 4A (recommended ≤3A continuous)
Conversion Efficiency	Up to 94%
Switching Frequency	~400 kHz
Voltage Adjustment	Multi-turn potentiometer
Protection	Thermal shutdown, overcurrent protection
Module Size	~43 mm × 21 mm × 14 mm
